Wide application : various shapes, state and nature of products (such as candy, chips, nuts, frozen dumplings, biscuits, mothballs, pet food, puffed food, hardware, plastic parts, etc.)
Automatic rotary packing machine adopt precision indexing device and PLC to control each action and working station to make sure the machine operates easily and does accurately.
Easy to operate: PLC controller, HMI system, fault indication on the touch screen.
The speed of this machine is adjusted by frequency conversion with the range, and the actual speed depends on type of products and pouch.
Stainless steel 304 /other materials ensure sanitation and safety, meet the GMP standard.
Internal grooved cam design: The technology with high precision, suits for max. packing speed: 65 cycles/min with stable running.
| Model | HIJ8-200R | HIJ10-200 | HIJ8-260 | HIJ8-300 |
| Pouch Type | Stand-Up pouch, Zipper pouch,3-side Sealing pouch, Flat pouch, etc. | |||
| Pouch Size(mm) | W80-200 L100-400 | W140-260 L100-400 | W180-300 L100-400 | |
| Filling Range | 10-2500g(Depending on type of products) | |||
Packing Speed (pouch/min) | 20-60 | 20-80 | 20-50 | 10-35 |
| Total Power | 3.3KW | 3KW | ||
| Compress Air Requirement | ≥0.6m³/min(supply by user) | |||
| Machine Weight | 1400kg | 1700kg | 1500kg | 1700kg |
Dimension (L*W*H) | 1890*1830*1430 | 2090*1500*1420 | 1890*1830*1430 | 2290*1500*1420 |
