DXDK600 BACK SEALING MACHINE

DXDK600 back sealing machine is a type of packaging machine that is specifically designed to create a back seal on packages. Back sealing machines are commonly used for packaging various products such as food items, pharmaceuticals, cosmetics, and more. HIJPACK offers high-quality stick pack machines for sale, ideal for businesses seeking efficient packaging solutions.

Get A Quote

Products

Specifications of the DXDK600 Back Sealing Machine

Model	DXDK600
Max output	450pcs/min
Packing material	Aluminum/plastic, paper/plastic, plastic/plastic composite film
Packing amount	0.4g-50g(0.8-100ml)
Core diameter	70-72 mm
Max width	600 mm
Max outer diameter	500 mm
Power supply	380V 50HZ
Total power	10KW
Dimension	1600X1550X2550 mm
Machine weight	1000 KG

The Features of the DXDK600 Back Sealing Machine

Sachet Making and Packaging: The back sealing machine is capable of making sachets, filling them with the desired product, sealing them, punching holes if required, counting the sachets, and printing batch numbers automatically.
Servo Motor Control: The back sealing machine utilizes a servo motor controlled by a computer to perform various functions such as pulling the sachet, tracking the eye mark for accurate positioning, determining the sachet length, and making the sachet. This ensures stable operation and accurate detection.
Back Seal and Angled Design: Sachets are sealed at the back, providing a secure and airtight seal. The four angles of the two sides of the sachet can be cut to a right angle or fillet, giving them a visually appealing and professional appearance. Additionally, an oblique easy tear design is incorporated, allowing users to conveniently open the sachets.
Optional Coding Methods: The back sealing machine offers three optional coding methods for marking the sachets. These include steel letter coding, laser coding, and ribbon coding. This allows for customization and flexibility in meeting specific coding requirements.
